OEM Thermal Imaging Binocular Military Night Vision Goggles

Place of Origin : China

Brand Name : OEM, ODM All Available

Certification : CE,FC,RoHS

MOQ : 10

Delivery Time : 3~7

Payment Terms : T/T. L/C, Western Union, Money Gram

Supply Ability : 30000PCS/Month

Brightness/Gain : Auto/Manual

IP ratings : IP67

Laser rangefinder : Measuring range 50m~5Km

FOV : 6°*4.8°(±5%)

Operating Time : 6 Hours continuous

USB : Yes

Operation temperature : -30℃- +55℃

Storage temperature : -40℃- +70℃

Contact Now

Best Quality Factory OEM Thermal Imaging Binocular Military Night Vision Goggles

Parameter:

IR Thermal Detector Type Uncooled FPA
Spectral Range 8~14um
Detector Resolution 640x512
Lens 73mm / F1.2
FOV 6°x4.2°
NETD 50mk@30℃
Frame rate 50HZ
Focusing method Electric focus
Digital Zoom 4x
　 　
Visible Optical Camera 　
Sensor 1/2.9″ CMOS
Pixel 1920(H)×1080(V)
Field of view 3°× 2.2°~12°× 8.8° continuous zoom lens
Focus Auto or manual
　 　
Brightness/Gain Auto/Manual
Electronic compass Angle measurement accuracy Azimuth angle 0.5°, pitch angle 0.3°
　 　
Laser rangefinder Measuring range 50m~5Km
Positioning system Beidou/GPS
Target information positioning ≤20m(CEP), observation distance 2Km
Display HD OLED binocular display (1280*1024), 0.61 inch
Polarity Black-hot, White-hot, Red-hot, Iron hot
Diopter adjustment Yes
Video and photo playback Local infrared and visible real-time recording and local playback
Battery type 18650 universal battery
Operating Time 6 Hours continuous
Battery charging Special charger
External video PAL
USB Yes
Operation temperature -30℃- +55℃
Storage temperature -40℃- +70℃
IP ratings IP67
Weight 1.8Kg
Size 210mm x 190mm x 85mm
Used for Night Vision,Searching,Scout
Detection Distance Human 1.5km / Vehicle 4km

Features:

  1. Using HD binocular OLED display with adjustable binocular visib ility
  2. Long-distance laser ranging , ranging distance> 5km
  3. Target positioning and self-positioning , report the target pos ition

OEM Thermal Imaging Binocular Military Night Vision GogglesOEM Thermal Imaging Binocular Military Night Vision GogglesOEM Thermal Imaging Binocular Military Night Vision Goggles
